DiagnosticDoIPTriggerVehicleAnnouncement.
更多...
#include <doip_trigger_announcement.h>
|
| ara::core::Result< void > | TriggerVehicleAnnouncement (std::uint8_t networkInterfaceId) |
| | This function will trigger the DM to send the vehicle announcement message on the specified network card. 更多...
|
| |
DiagnosticDoIPTriggerVehicleAnnouncement.
- Swsid
- SWS_DM_00820
- 符合标准
- Yes
- 非标原因
- N/A
- 种类
- class
- 符号
- DoIPTriggerVehicleAnnouncement
- 范围
- namespace ara::diag
- 基类
- N/A
- 分类
- ara
- 头文件
- ara/diag/doip_trigger_announcement.h
- 注解
- The DoIPTriggerVehicleAnnouncement service is used by the APP to notify the DM to send a vehicle announcement message.
- 模板参数
-
在文件 第 行定义.
◆ GetDoIPTriggerVehicleAnnouncement()
This function will return an object of DoIPTriggerVehicleAnnouncement.
- 模板参数
-
- 参数
-
| [in] | N/A | |
| [out] | DoIPTriggerVehicleAnnouncement& | |
| [in,out] | N/A | |
- 返回
- DoIPTriggerVehicleAnnouncement &
- 注解
- [Error]: N/A
- 异常
-
- Swsid
- N/A
- 符合标准
- no
- 非标原因
- return value non-standard
- 种类
- function
- 可见
- public
- 线程安全
- N/A
- Fireandforget
- N/A
- 错误
- N/A
- 头文件
- ara/diag/doip_trigger_announcement.h
- 异常安全
- N/A
- 分类
- ara
在文件 第 行定义.
◆ TriggerVehicleAnnouncement()
| ara::core::Result< void > ara::diag::DoIPTriggerVehicleAnnouncement::TriggerVehicleAnnouncement |
( |
std::uint8_t |
networkInterfaceId | ) |
|
This function will trigger the DM to send the vehicle announcement message on the specified network card.
- 模板参数
-
- 参数
-
| [in] | networkInterfaceId | network card id std::uint8_t networkInterfaceId. |
| [out] | ara::core::Result<void> | |
| [in,out] | N/A | |
- 返回
- ara::core::Result<void>
- 注解
- N/A
- 异常
-
- Swsid
- N/A
- 符合标准
- no
- 非标原因
- return value non-standard
- 种类
- function
- 可见
- public
- 线程安全
- N/A
- Fireandforget
- N/A
- 错误
- ara::diag::DiagErrc::kFailed
- 错误
- ara::diag::DiagErrc::kGenericError
- 头文件
- ara/diag/doip_trigger_announcement.h
- 异常安全
- N/A
- 分类
- ara
在文件 第 行定义.
引用了 ara::diag::kFailed , 以及 ara::diag::kGenericError.
